Z41W/Y美標閘閥300Lb
溫馨提示:歡迎訪問凱工流體官網(wǎng),如需訂購請來電咨詢,謝謝!
聯(lián)系人:林先生
手 機:13600685351
電 話:0577-66996166
傳 真:0577-66996168
手 機:13600685351
電 話:0577-66996166
傳 真:0577-66996168
型號:Z41W/Y~300Lb
適用溫度:200℃~500℃
材質:CF8、CF3、CF8M、CF3M
應用規(guī)范Application Norm
1、設計制造按API STD.600
2、結構長度按ANSI B16.10
3、法蘭型式及尺寸:150/300/600Lb按ANSI B16.5JIS 10K、20K按JIS B2212~B2214
4、閥門檢查和試驗按APISTD.598
1. Design Manafacfure According to API STD.600
2.Face to Face According to ANSI B16.10
3.150/300/600Lb End Flange Dimension According to ANSI B16.10Accoring to JIS B2212-B2214
4.Valve Check and Test According to API598
結構Structure
B.B; OS & Y Characteristic:B.B; OS & Y
